The 2015 Dodge Charger is a beast on the road, but like any car, it can have its quirks. One issue that sometimes crops up is related to the fuel pump relay. If your Charger is sputtering, stalling, or just plain refusing to start, a faulty fuel pump relay might be the culprit. Let's dive into the details of this issue, how to diagnose it, and what you can do to get your Charger back on the road.

Understanding the Fuel Pump Relay

So, what exactly does the fuel pump relay do? Essentially, it's an electrical switch that controls the power supply to your fuel pump. When you turn the ignition, the car's computer sends a signal to the fuel pump relay, which then allows electricity to flow to the fuel pump. The fuel pump then pumps fuel from the tank to the engine. Without a properly functioning fuel pump relay, the fuel pump won't get the power it needs, and your engine won't get the fuel it needs to run.

The fuel pump relay is a small, inexpensive component, but its failure can bring your car to a complete standstill. It acts as an intermediary, receiving signals from the car's computer and then activating the fuel pump. This relay is designed to handle the electrical load required to power the fuel pump, preventing the car's computer from being directly subjected to the high current draw. The design ensures that the computer's sensitive circuits are protected, and the fuel pump receives a consistent and reliable power supply.

Over time, the fuel pump relay can degrade due to several factors. One of the most common causes of failure is simply age and wear. Relays have moving parts that can wear out over time, leading to reduced performance and eventual failure. Environmental factors such as heat and moisture can also contribute to the degradation of the relay's internal components. In addition, electrical surges or spikes in the car's electrical system can damage the relay, causing it to malfunction. Regular maintenance and inspection of the relay can help identify potential problems early on, preventing unexpected breakdowns and ensuring the reliable operation of the fuel pump.

Symptoms of a Failing Fuel Pump Relay

Okay, so how do you know if your 2015 Dodge Charger has a fuel pump relay problem? Here are some common symptoms to watch out for:

• Engine Won't Start: This is the most obvious sign. If you turn the key and the engine cranks but doesn't start, the fuel pump might not be getting power. The starter motor engages, turning the engine over, but without fuel, combustion cannot occur. This symptom is particularly noticeable after the car has been sitting for a while, as the fuel system may have lost pressure, making it harder to start. In some cases, the engine might start briefly and then stall, indicating that the fuel pump is receiving intermittent power.
• Engine Stalling: If the engine starts but stalls shortly after, especially when idling or at low speeds, it could be due to an intermittent fuel supply. The fuel pump relay might be cutting power to the fuel pump sporadically, causing the engine to die unexpectedly. This stalling can be dangerous, especially in heavy traffic, as it can leave you stranded in a potentially hazardous situation. The engine might restart after a few attempts, but the stalling is likely to recur until the relay is replaced.
• Loss of Power: Experiencing a sudden loss of power while driving, especially when accelerating or going uphill, can indicate a fuel delivery issue. The fuel pump may not be able to supply enough fuel to the engine under increased load, resulting in a noticeable decrease in performance. This can manifest as hesitation, sputtering, or a complete loss of power. The car might struggle to maintain speed, and you might notice that it's difficult to climb hills. This symptom is a clear sign that the fuel system is not functioning correctly and needs immediate attention.
• Unusual Noises: Sometimes, you might hear a clicking sound from the relay itself, which indicates it's failing. Relays contain moving parts that click when they switch on and off. If you hear rapid or erratic clicking coming from the relay box, it could be a sign that the relay is malfunctioning. This clicking is often caused by the relay attempting to make contact but failing due to worn or damaged internal components. Pay attention to any unusual sounds coming from the electrical components of your car, as they can often provide valuable clues about potential problems.
• Fuel Pump Not Activating: You should normally hear a brief whirring sound from the fuel pump when you first turn the ignition on. If you don't hear this sound, the fuel pump may not be getting power. The fuel pump is located inside the fuel tank, and its sound is usually audible for a brief moment when it primes the fuel system. If you don't hear this sound, it could be a sign that the fuel pump relay is not sending power to the pump. This symptom is particularly telling if you've noticed other signs of fuel pump relay failure, such as difficulty starting or stalling.

Diagnosing the Fuel Pump Relay

Okay, guys, so you suspect the fuel pump relay is the problem. How do you confirm it? Here's a simple diagnostic process:

1. Locate the Fuel Pump Relay: Consult your 2015 Dodge Charger's owner's manual or a reliable online resource to find the location of the fuel pump relay. It's usually in the fuse box, either under the hood or inside the cabin. The location can vary depending on the specific model and trim of your Charger. Once you've found the fuse box, refer to the diagram on the inside of the lid to identify the fuel pump relay. The diagram will show the location of each relay and fuse, making it easier to find the correct one.
2. Check the Relay: Once you've located the fuel pump relay, inspect it for any visible signs of damage, such as cracks, burns, or corrosion. A damaged relay might have a melted or distorted appearance, indicating that it has overheated. Corrosion can also be a sign of moisture damage, which can affect the relay's performance. If you notice any of these signs, it's a clear indication that the relay needs to be replaced. However, even if the relay looks fine, it could still be faulty, so further testing is necessary.
3. Swap with an Identical Relay: This is the easiest test. Find another relay in the fuse box that's identical to the fuel pump relay (often the horn relay or another non-essential relay). Swap them. If your car starts after the swap, the original relay is likely the problem. Before swapping the relays, make sure that the replacement relay has the same specifications and amperage rating as the fuel pump relay. Using a relay with a different rating could damage the electrical system. After swapping the relays, try starting the car to see if the problem is resolved. If the car starts and runs normally, the original relay is likely faulty and needs to be replaced.
4. Use a Multimeter: If you have a multimeter, you can test the relay for continuity. Remove the relay and use the multimeter to check if the coil inside the relay is intact. You should also check if the relay switches properly when voltage is applied. A multimeter is a versatile tool for diagnosing electrical problems. To test the relay, set the multimeter to the continuity setting and connect the probes to the relay's terminals. You should hear a beep or see a reading indicating continuity. If there's no continuity, the relay is likely faulty. You can also test the relay's switching function by applying voltage to the coil terminals and checking if the switch closes. If the relay doesn't switch properly, it needs to be replaced.

Replacing the Fuel Pump Relay

If you've confirmed that the fuel pump relay is the problem, replacing it is usually a simple and inexpensive fix. Here's how:

1. Purchase a New Relay: Buy a replacement fuel pump relay that's specifically designed for your 2015 Dodge Charger. You can find these at most auto parts stores or online retailers. Make sure to get a relay that matches the original relay's specifications, including the voltage and amperage ratings. Using a relay with the wrong specifications could damage the electrical system or cause other problems. Check the owner's manual or consult a parts specialist to ensure you're getting the correct replacement relay.
2. Remove the Old Relay: Locate the fuel pump relay in the fuse box (as described earlier) and gently pull it out. You may need to use a small tool, such as a fuse puller or a pair of pliers, to remove the relay. Be careful not to damage the surrounding components or the fuse box itself. Before removing the relay, make sure the ignition is turned off to prevent electrical shocks or damage to the car's electrical system. Gently wiggle the relay back and forth while pulling it out to avoid bending the pins.
3. Install the New Relay: Align the pins of the new relay with the corresponding slots in the fuse box and gently push it in until it's fully seated. Make sure the relay is firmly in place and that the pins are making good contact with the fuse box terminals. A loose connection could cause the relay to malfunction or fail prematurely. Double-check the orientation of the relay to ensure it's installed correctly. Refer to the fuse box diagram if needed. Once the new relay is installed, test the car to see if the problem is resolved.
4. Test Your Car: Start your 2015 Dodge Charger to see if the issue is resolved. If the engine starts and runs smoothly, you've successfully replaced the fuel pump relay. If the problem persists, there may be another issue with the fuel system or the car's electrical system. In this case, it's best to consult a qualified mechanic for further diagnosis and repair. Check for any other symptoms or error codes that might provide additional clues about the problem. A thorough inspection of the fuel system and electrical system can help identify the root cause of the issue.

Other Potential Causes

While the fuel pump relay is a common culprit, it's not the only thing that can cause these symptoms. Other potential causes include:

• Faulty Fuel Pump: The fuel pump itself could be failing. If the fuel pump is not providing adequate fuel pressure, it can cause the engine to stall, lose power, or fail to start. Fuel pumps can wear out over time due to age, contamination, or overheating. Testing the fuel pressure can help determine if the fuel pump is functioning correctly. A fuel pressure gauge can be used to measure the pressure at the fuel rail. If the pressure is below the specified range, the fuel pump may need to be replaced.
• Clogged Fuel Filter: A clogged fuel filter can restrict fuel flow to the engine. The fuel filter is designed to remove impurities from the fuel, preventing them from entering the engine. Over time, the filter can become clogged with dirt, debris, and other contaminants. This can restrict fuel flow, causing the engine to stall, lose power, or fail to start. Replacing the fuel filter is a relatively simple and inexpensive maintenance task that can improve fuel efficiency and performance.
• Wiring Issues: Damaged or corroded wiring can cause intermittent fuel pump operation. Inspect the wiring harness and connectors for any signs of damage or corrosion. Damaged wires can cause short circuits or open circuits, which can affect the fuel pump's performance. Corroded connectors can also restrict electrical flow, leading to intermittent operation. Cleaning or replacing damaged wiring and connectors can help restore proper fuel pump function.
• Crankshaft Position Sensor: A failing crankshaft position sensor can cause the engine to not start. The crankshaft position sensor provides information to the car's computer about the position and speed of the crankshaft. If the sensor is not functioning correctly, the computer may not be able to properly time the ignition and fuel injection, preventing the engine from starting. Testing the crankshaft position sensor with a multimeter can help determine if it's functioning correctly. If the sensor is faulty, it needs to be replaced.

Conclusion

The fuel pump relay in your 2015 Dodge Charger is a small but mighty component. If you're experiencing starting issues, stalling, or power loss, don't overlook this simple fix. By following these diagnostic steps and replacement instructions, you can often resolve the problem yourself and save some serious cash. However, if you're not comfortable working on your car, it's always best to consult a qualified mechanic. Stay safe and happy driving!
