Hey guys! Are you digging into the Hyundai R300LC-9S and need all the juicy details on its specs? You’ve landed in the right spot. Let's break down everything you need to know about this beast of a machine, from its engine to its dimensions, so you can get a real feel for what it can do. Whether you're an operator, a fleet manager, or just a machinery enthusiast, understanding the specifications of the R300LC-9S is super important.

Engine Specifications

Let's kick things off with the heart of the machine – the engine. The Hyundai R300LC-9S is equipped with a robust engine that provides the necessary power for heavy-duty operations. Understanding the engine specs is critical for assessing the machine's overall performance and capabilities.

Engine Model and Type

The Hyundai R300LC-9S typically features a high-performance diesel engine. While specific models may vary, it generally uses an engine designed for reliability and efficiency. Diesel engines are favored in heavy machinery for their torque and durability.

• Model: Often, you'll find this excavator using a Cummins or similar tier engine known for its dependability.
• Type: It's a four-cycle, turbocharged, and air-cooled diesel engine. Turbocharging boosts the engine's power output by forcing more air into the cylinders, enhancing combustion and overall performance. Air-cooled systems help maintain optimal operating temperatures, preventing overheating during intense work.

Horsepower and Torque

The horsepower (HP) and torque figures are crucial indicators of the engine's capability to handle demanding tasks. Higher horsepower means more power for digging and lifting, while higher torque provides the force needed to move heavy loads.

• Horsepower: The Hyundai R300LC-9S generally boasts around 222 HP (166 kW). This allows it to tackle a wide range of tasks efficiently.
• Torque: Torque is equally important, and this model delivers approximately 723 lb-ft (981 Nm). This high torque output ensures that the excavator can handle tough digging conditions and lift heavy materials without bogging down.

Displacement and Cylinders

• Displacement: The engine displacement is usually around 6.7 liters. This volume indicates the total swept volume of all the engine's cylinders, influencing its power and efficiency.
• Cylinders: Typically, it features a six-cylinder configuration. Six-cylinder engines provide a good balance of power and smoothness, making them ideal for heavy machinery.

Fuel System and Capacity

Knowing the fuel system and capacity is essential for planning operations and understanding the excavator's range.

• Fuel System: The R300LC-9S utilizes a direct injection fuel system. Direct injection improves fuel efficiency and reduces emissions by precisely delivering fuel into the cylinders.
• Fuel Capacity: The fuel tank usually holds around 158.5 gallons (600 liters). This large capacity allows for extended operation without frequent refueling, maximizing productivity on the job site.

Hydraulic System Specifications

The hydraulic system is what gives the Hyundai R300LC-9S its muscle, controlling everything from the boom and arm to the bucket. It’s super important to understand how this system works to really appreciate the excavator's capabilities.

Pump Type and Flow Rate

The hydraulic pump is the heart of the hydraulic system, responsible for generating the pressure needed to power the excavator's various functions. The flow rate determines how quickly these functions can be performed.

• Pump Type: The Hyundai R300LC-9S typically uses variable displacement piston pumps. These pumps adjust the flow rate based on the demand, improving efficiency and reducing energy waste. They are known for their reliability and ability to maintain consistent performance under varying loads.
• Flow Rate: The main pumps usually provide a combined flow rate of around 152 gallons per minute (575 liters per minute). This high flow rate ensures quick and responsive operation of the excavator's hydraulic functions, enhancing productivity.

Hydraulic Pressure

The hydraulic pressure dictates the force that the excavator can exert. Higher pressure means greater digging and lifting capabilities.

• System Pressure: The main hydraulic system operates at a pressure of approximately 5,000 psi (345 bar). This high pressure allows the excavator to handle tough digging conditions and lift heavy loads with ease.
• Pilot Pressure: The pilot system, which controls the main hydraulic valves, typically operates at a lower pressure, around 550 psi (38 bar). This ensures smooth and precise control of the excavator's movements.

Hydraulic Cylinders

The hydraulic cylinders are responsible for converting hydraulic pressure into mechanical force, powering the boom, arm, and bucket.

• Boom Cylinders: The boom cylinders are large and powerful, providing the lifting force for the excavator. They are designed to withstand high pressures and heavy loads.
• Arm Cylinder: The arm cylinder controls the movement of the arm, allowing the operator to dig and reach efficiently.
• Bucket Cylinder: The bucket cylinder controls the digging and dumping action of the bucket. It is designed for precise control and high breakout force.

Hydraulic Oil Capacity

• Hydraulic Oil Capacity: The hydraulic oil reservoir usually holds around 79.3 gallons (300 liters). This large capacity ensures that the hydraulic system remains properly lubricated and cooled, preventing overheating and extending the life of the components.

Dimensions and Weight

Okay, let’s talk about size and weight. These measurements are super important for figuring out where you can use the R300LC-9S and how you’ll need to transport it. Knowing the dimensions and weight helps you plan your projects better and ensures you can move the machine safely.

Operating Weight

The operating weight includes the weight of the excavator plus all attachments, fluids, and a standard operator. This figure is critical for determining transportation requirements and ground pressure.

• Operating Weight: The Hyundai R300LC-9S typically weighs around 67,241 pounds (30,500 kg). This substantial weight provides stability and digging power.

Overall Dimensions

Understanding the overall dimensions helps you determine whether the excavator can operate in confined spaces and navigate through tight areas.

• Overall Length: Approximately 34 feet 5 inches (10.5 meters).
• Overall Width: Around 10 feet 6 inches (3.2 meters).
• Overall Height: Roughly 10 feet 8 inches (3.3 meters).

Digging Reach and Depth

Digging reach and depth are crucial for understanding the excavator's capabilities in various applications.

• Maximum Digging Reach: The R300LC-9S can reach up to 34 feet 9 inches (10.6 meters).
• Maximum Digging Depth: It can dig to a maximum depth of 22 feet 6 inches (6.9 meters).
• Maximum Digging Height: Around 32 feet 2 inches (9.8 meters).

Tail Swing Radius

The tail swing radius is important for understanding how much space the excavator needs to rotate without hitting obstacles.

• Tail Swing Radius: Typically around 10 feet 2 inches (3.1 meters). This relatively short tail swing radius allows the excavator to work in tighter spaces.

Undercarriage Specifications

The undercarriage is the foundation of the excavator, providing stability and mobility. Understanding its specifications is essential for assessing the machine's performance on different terrains.

Track Type and Width

• Track Type: The Hyundai R300LC-9S uses heavy-duty tracks designed for durability and traction. These tracks are built to withstand the rigors of demanding job sites.
• Track Width: The standard track width is around 2 feet 11 inches (900 mm). Wider tracks provide better stability and lower ground pressure, making the excavator suitable for soft or uneven ground.

Track Length and Ground Contact Length

• Track Length: The track length on the ground is approximately 13 feet 1 inch (4 meters). This length provides a stable base for digging and lifting operations.
• Ground Contact Length: Similar to the track length, the ground contact length ensures optimal weight distribution and traction.

Ground Pressure

• Ground Pressure: The ground pressure is around 7.2 psi (0.50 kg/cm²). Lower ground pressure allows the excavator to work on sensitive surfaces without causing excessive damage.

Bucket Specifications

Alright, let’s dig into the bucket specs! The bucket is what gets the work done, so knowing its capacity and digging force is super important. This info helps you pick the right bucket for the job and understand how efficient your excavator will be.

Bucket Capacity

The bucket capacity determines how much material the excavator can move in each cycle. Different bucket sizes are available for various applications.

• Standard Bucket Capacity: The standard bucket capacity for the Hyundai R300LC-9S ranges from 1.05 to 1.57 cubic yards (0.8 to 1.2 cubic meters). This capacity is suitable for general excavation and loading tasks.

Digging Force

• Bucket Digging Force: The bucket digging force is approximately 37,264 pounds (165.7 kN). This high digging force allows the excavator to break through tough materials and dig efficiently.
• Arm Digging Force: The arm digging force is around 26,455 pounds (117.7 kN). This force contributes to the excavator's overall digging performance and ability to handle challenging tasks.

Bucket Width

• Bucket Width: The bucket width typically ranges from 3 feet 3 inches to 4 feet 7 inches (1.0 to 1.4 meters), depending on the bucket capacity and application.

Other Notable Features

Beyond the core specs, the Hyundai R300LC-9S comes packed with features that boost its performance and make the operator's life easier. These include advanced control systems, comfortable cabs, and easy maintenance access.

Control System

• Advanced Control System: The R300LC-9S features an advanced control system that optimizes engine and hydraulic performance. This system includes features like power boost and automatic idle, enhancing efficiency and reducing fuel consumption.

Cab Features

• Comfortable Cab: The cab is designed for operator comfort and productivity. It includes features like adjustable seating, climate control, and a user-friendly instrument panel.

Maintenance Access

• Easy Maintenance Access: The excavator is designed for easy maintenance, with convenient access to service points and filters. This reduces downtime and simplifies routine maintenance tasks.

Conclusion

So, there you have it! A deep dive into the specifications of the Hyundai R300LC-9S. Knowing these specs helps you understand what this excavator can do and how it can boost your project efficiency. From its powerful engine and hydraulic system to its carefully designed dimensions and bucket, the R300LC-9S is built for serious performance. Whether you're digging, lifting, or loading, this machine is ready to tackle the toughest jobs. Keep these details in mind, and you’ll be well-equipped to make the most of this incredible piece of machinery. Happy excavating, folks!
